What Can Be Customized on Smart Mirror Electronics | DZOPTO
Touch, power, LED strip and demister options for OEM and ODM mirror projects.
Tags: OEM ODM, Custom Smart Mirror, Touch Switch, 15mm Power Supply, LED Strip, Demister Film, LTZN-03D-SX, LTZN-12V, DZOPTO
A finished mirror only shows the icons. The custom work is the electronics behind the glass.
This page lists what DZOPTO can change on catalogue platforms. It is not a finished-mirror factory page. Send glass thickness, functions and quantity; we return a recommended BOM.
1. Touch switches
Split example: LTZN-03D-SX
Integrated example: LTZN-01S-YT1201
| Item | Options |
|---|---|
| Keys | 1-key, 2-key, 3-key |
| Structure | Split, or integrated touch + power |
| Sensing | Capacitive, IR hand-wave, radar |
| Functions | On/off, dimming, color temperature, defogger, RGB, memory, time/temperature |
| Glass | 3–5 mm typical; confirm touch area 18–20 mm |
| Icon pitch | e.g. 27.5 mm on LTZN-03D-SX; other pitches on request |
| Indicators | Standby / working color |
| Cables | Length, connector, polarity marks |
OEM: you send icon layout and glass thickness.
ODM: we start from LTZN-03D-SX or an integrated YT1201 platform and drop unused functions.
2. Power supplies
15 mm series: LTZN-12V-24W to 72W
| Item | Options |
|---|---|
| Output | DC12V |
| Ratings | 24W / 2A, 36W / 3A, 48W / 4A, 60W / 5A, 72W / 6A |
| Body | 15 mm ultra-slim for tight cavities |
| Input | AC 200–240V, 50/60Hz on this series |
| Protection | Short circuit, overload, over temperature |
| Use | LED bathroom mirrors, cabinets, vanity and full-length lights |
Pick wattage from LED strip load + demister load, then leave margin. Do not size the supply to the strip alone if the film runs at the same time.
3. LED strips
Catalogue: LED Strips
| Item | Options |
|---|---|
| Width | 8 mm, 12 mm (common) |
| LED count | 72, 96, 120, 168, 190 — state the cut length with the count |
| LED type | SMD 2835 common; CRI >90 available |
| Board | Single-sided, double-sided, die-cut |
| Length | Cut to the lighted edge |
| CCT | Confirm warm / neutral / cool or dual-white |
Tell us the lighted perimeter, not only “one strip per mirror”.
4. Demister film
Catalogue: Anti-Fog Film
Reference model: LTZN-FW4080
| Item | What to send |
|---|---|
| Size | Heated area, not full glass size |
| Voltage / power | Must match the chosen supply |
| Shape | Rectangle is standard; other outlines on request |
| Lead | Exit position and length |
Film plus LEDs share one 12V budget. A 60W supply cannot run a large film and a long high-density strip at full load.
What we do not customize here
Complete finished mirrors
Whole-mirror CE / UL in place of your fixture assessment
A logo on the carton only (that is private label, not OEM)
Sales and documents: Dongguan Dingzhuo Optoelectronics Co., Ltd.
Production: Xuchang Lietuo Intelligent Electronics Co., Ltd.
How to send a brief
Mirror type and size
Glass thickness
Functions
Destination market
Monthly quantity
Drawing or photo, if you have one
Standard catalogue parts: no MOQ. New custom items: about four months to mass production.
Website: www.led.vip
Tel / WhatsApp: +86-13510849696
DZOPTO — customize the four parts behind the glass.
